Urbando Gaiety

STRUCTURE

RCC Framed Structure designed for Seismic Zone 3, Foundation Type - Isolated & Raft Antitermite at Plinth Level

Steel Grade-Fe550/Fe550D from Kamatchi/Tulsyan; RMC as per design Mix Masonry works - Solid Block (Outer wall of 8" & Inner walls of 4")

Ceiling - Putty Work

Clear Height - 9'6" Floor to Floor

OTS Area covered with Polycarbonate sheets

FLOORING

Glazed Vitrified Tile for all rooms with KAJARIA or equivalent size of 2'X4' for Living/Dining/Bedroom and MATT 2'X4' for Kitchen & Utility

Granite Flooring in all Common Areas & Staircase

Balcony with size 1'X 1' Vitrified Matt Finish Tile

Toilet: Matt finish vitrified tile up to the false ceiling level

KITCHEN

Open Kitchen

Matt finish vitrified Dado tile - laid 2 feet above the counter

Single bowl 10" Depth stainless steel sink of reputed brand

Provision for RO point, Exhaust fan and Chimney

Provision for washing machine & Dish Washer in utility area

Power point for Chimney, Refrigerator, Microwave oven, Mixer / grinder

TOILETS

Toilets: Comes with wall mounted EWC of Kerovit / Kohler or equivalent

Provision for health faucet in all toilets

CP fittings, hot and cold-water mixer unit for showers (Kohler or equivalent)

Wall mounted washbasin in all toilets (Kerovit or equivalent)

Wall Hung basin in dining area

DOORS & WINDOWS

Main Entrance Door: Size - 4' X 8' Double side veneered 40mm thick flush door with Teak frame and Melamine polished finish

Bedroom Door: Size-3'X7'-Wooden frame with 35mm thick shutter with two side Laminate Finish and polished frames

Toilet Door: Size -2'6"X7"-Wooden frame with 32mm thick shutter with two side Laminate Finish and polished frames

Locks, Tower Bolts & Handles from Godrej / Yale or Equivalent

Aluminium windows for all common areas

French Door: UPVC with clear Toughened glass

Window: UPVC with 6mm Toughened glass and MS Grill

UPVC with frosted glass in toilet ventilators (openable Type) with an exhaust fan provision

PAINT FINISHES

Internal Walls and Ceiling: Smooth putty finish with 2 coats of acrylic emulsion paint of reputed brand over one coat of primer

External Walls: Textured finish with 2 coats of weatherproof exterior emulsion paint of reputed brand

MS Grill: Enamel paint over one coat of Zinc chromate primer

ELECTRICAL

Concealed insulated fire retard low smoke wiring (Fybros/Anchor or equivalent) 3-phase electric supply with MCB & RCCB

Provision for Telephone points in living area

Provision for Internet Connection in living and master bedroom

Modular switches (Litaski / Great White or equivalent)

Integrated DTH system using Triax Sat Wave System

Miniature Circuit Breaker (MCB) for each room shall be provided through the main distribution box set-up in each flat

Provision for horizontal geyser, exhaust fan in all bathrooms

Split AC provision for living, dining and all bedrooms with Concealed Drain Provision

One Residual Current Circuit Breaker (RCCB) with 30m A sensitivity in each flat distribution box

PLUMBING

CPVC concealed water lines for internal lines from Astral or equivalent

UPVC/PVC pipes for external lines from Astral or equivalent

Bore wells/metro water, underground and overhead storage tanks (of suitable capacity) with pumps

UG sump capacity of 10000 Ltrs for Metro: 93000 Ltrs for Borewell raw water & Filtered water with partition

POWER BACK UP

D.G. Set backup with AMF for all common amenities including clubhouse, lifts, common lighting, motor and pump

Apartment Power Backup with Load Limiter: 3BHK - 1.5KVA, 2BHK - 1.5KVA
