SUPER STRUCTURE
Outer walls
9" thick Brick Wall
Partition walls
41/2" thick Brick Wall
Lintel height
7 Feet
Loft and shelves
One side in Bed Room and Kitchen
Roof height in all floors
10 Feet (Floor to Floor)
Stilt Floor - 10 Feet
Basement Level 2 1/2 Feet
Parapet wall height from Roof Level
39"
Weathering course
Brick jelly with surki and pressed Tiles
Plastering
Internal 1:4 cm
External 1:5 cm
Ceiling - 1:3 cm
ELECTRICAL
Wiring (Finolex or Equivalent)
Light points - 1/18 wire
5 amps point - 3/20 wires
15 amps points - 7/20 wires
Switches
Legrand or Equivalent modular switches
Circuit breakers
S.M.B. boxes with MDS / Legrand Circuit Breakers
JOINERIES
Main door
First quality - Both side compressed teak paneled door
Other doorframes
4" x 2 1/2" first quality Kongu / Padak frame
Flush door shutter
Both side Compressed Paneled Door
Windows
Powder coated aluminums openable / UPVC windows with M.S. Grills for safety
PAINTING
Inner walls
Primer + putty (2 coats) + Emulsion (2 coats)
Wood surfaces
Primer Putty and two coats of Asian / ICI enamel paint
Grill surfaces
Enamel paint - Two coats
Exterior walls
Finolex or Equivalent
PLUMBING
Toilet
Concealed plumbing
Pipe
15mm CPVC pipe (hot & cold) CPVC
Common toilet
I.W.C. / E.W.C. - White
Attached toilet
E.W.C. - Cascade model White
TILING & FINISHING
Main flooring
First quality vitrified tiles of regular series Skirting - 4" of the same flooring tile @ Rs.50/- per sq ft
Bathrooms
Tiled up to 7' ht @ Rs.50/- per sq ft
Kitchen
19 mm thick 2'0" width black granite and 2'0" height tiling
Sink
Carysil Sink / Granite Sink
Sanitary wares
White (Parry ware / Hind ware)
C.P. Fittings
ESS ESS (or) Parry ware (or) Jaguar
Bore Well
2 Nos + 2 Motors
Sump
20,000 Ltrs Capacity - 2 Nos
