TYPE OF FOUNDATION AND STRUCTURE
RCC Framed Structure with RCC Columns @ regular intervals with isolated footings. All the columns will be interlinked by Plinth beam.
ROOF HEIGHT
10’0” for Ground floor, First floor, Second floor & Third floor including slab thickness, for 8’6” head room height including slab thickness normally roof thickness will be 4.5” to 5”.
SUPER STRUCTURE
External walls will be non load bearing 8” Solid block / Brick Masonry with C.M 1:6 & Internal walls will be non load bearing 4” Solid block brick masonry Walls with C.M 1:4 with 2nos of steel strips at every 3’0” interval (where necessary)
ROOF TREATMENT
Terrace floor weathering course will be used pressed clay tile finish.
LOFT
RCC loft of 1.5” thick with necessary bearing on one side in bed room and kitchen, hall with be no loft & cupboard, wood work will be extra cost.
ELECTRICAL
Concealed three phase electricity supply with FRLS wiring with Anchor Roma Modular switches will be used.
Light point 1 sq mm
Power point 15 amps & 5 amps
A/c power 4 sq mm
Geyser 5 sq mm
Inverter wiring included 1 Fan, 1 Light, 1 Socket for Living, Bed rooms, kitchen & 1 Light, 1 Socket for toilet.
KITCHEN
RCC or Cuddapah Slab will be 12’0” length with Black Galaxy granite top at the cost of Rs. 120/sft will be laid.
24” x 18” SS Sink with or without drain board will be provided
Above platform 4’0” height tiles will be laid .
FITTINGS
All fittings are (Lock, hinges, tower bolt etc) SS hardware except main door. Main door will be brass (Lock, hinges, tower bolt) or Antique.
FLOORING
Entire flat will have 2’ x 2’ Vitrified tiles flooring of basic colors will be laid. Balcony and passage flooring anti skid tile
TOILET
Walls will be finished with colored glazed tiles up to ceiling height 10” x 13” (Kajaria / Johnson) approved design for all toilet wall, toilet floor will be finished 1’ x 1’ ceramic antiskid tiles (fittings shall be one wash basin, closet, shower with arm, 2 in 1 wall mixer other than this are extra)
PAINTING
Interiors 1 coat of water base primer finished with 1 coat putty, 2 coats of premium emulsion paint will be used.
Exteriors & Ceiling 1 Coat of White Cement finished with 2 Coats of Apex.
PARAPET
Parapet wall will be 3’6” height with 4.5” wall with both side plastering necessary rings with be provided in terrace.
HEAD ROOM
Head room will be 8’6” height 9” outer wall with 4” thick roof will be laid terrace door grill safety gate will be provided.
