Foundation
RCC Isolated Footing as per Structural Drawing.
Basement - 2'ht from existing Ground level.
Superstructure
The Construction will be with framed structured as per structural design and
using Red Bricks.
Joineries
Main door : 1 Quality Teakwood frames with solid door and others with
2nd quality Teakwood frames with ?ush door's (Skin door).
Windows
UPVC Sliding window's.
Flooring
2' X 2' Vitrified tiles fooring with 4” skirting. Basic Rate 45/- Sq.ft.
Kitchen
Granite Slab Platform over RCC Slab and S.S Prince make sink with normal
bowl sink (Stainless Steel) will be provided and (2'0 Height) Ceramic
Glazed tiles above cooking counter).
Toilets
Antiskid ceramic fooring. Tiles Height 18” x 12” upto 7' ht. (Sun heart)
Basic Rate 30/- Sq.ft.
Staircase flooring
Granite
Loft & cupboards
Two bedroom and kitchen shall be provided with one loft, and kadappa
slabs shelfs without shutters.
Electrical
All Switches are modular switches, (Great White Switches) 3 phase change
over switch.
Hall Cum Dining
One Bell point, six lights points, two fan points and five nos five amps plug
point T.V & Telephone point 15 amps plug point.
Bedrooms
Two Light points, one-fan points and two 5 amps plug point. Two Bedroom
alone shall be provided with 15 A, power plug for A/c, T.V & Telephone point.
Kitchen
Two Light points, one 15 Amps Plug point, one exhaust fan point, one Ro Plug
Point, Two 5 Amps Plug Point.
Toilets
Two Light points and one 15 amps Power Plug and one 5 Amps Plug points in
each toilet.
Balcony
One Light Point, One 5 Amps Plug Point.
Electrical main board
EB Meter Panel Board.
Sanitary & Plumbing
White Colour EWC - Parry Ware, White Colour Washbasin – Parry Ware
CP Fittings - Parry Ware.
Painting
The Maindoor will be melamine polished other doors will be painted with
enamel paint. The ceiling will be white Trac tor Emul s ion,
Inner walls with putty and Tractor Emulsion, Outer walls with Asian Apex,
grills with Enamel painting.
Borewell
2 Bore well shall be provided and this borewell will be connected to overhead
tank. Car parking will be of Antis Kid tiles Paving block shall be provided in set
back areas.
Lift
6 Passenger lift will be provided.
