Radha

Type of Construction

RCC Framed Structure.

Walls

Walls will generally be plastered and painted (Asian Paints / Nerolac / Berger) inside and outside.

In the toilets, wall will be covered with ceramic tiles up to 7 feet height.

In the wash area, ceramic tiles will be provided up to the parapet wall height or will be in line with kitchen dado.

Ceramic tiles will be plain soft color of builder’s Choice.

Flooring

Flooring will be good quality 2 X 2 vitrified tiles for entire flat except in 2 bedrooms (including on Master bedroom) toilet and wash area.

Toilet and wash area will be provided with 1 X 1 ceramic tiles.

Master Bedroom and one more bedroom (of purchaser’s choice) will be provided with wooden flooring.

Doors

Main door frame will be of 1st Quality teak wood doors finished with varnish with Brass fitting.

Other doors will be good quality wood frames flush doors or equivalent painted on both sides.

Windows and Ventilators

Pre-fabricated UPVC Bay windows for Master bedroom & others standard size windows will be provided.

French sliding windows for Hall Sit-out.

2x2 size Ventilators with glass louvers & Fan exhaust ventilation for toilets.

Kitchen

G 20 Black Granite slab will be provided for the kitchen cooking platform.

A Single bowl stainless steel sink with drain board will be provided.

Plumbing and Sanitary Fittings

Concealed plumbing lines from the overhead tank for each floor.

All closets and wash basins will be in white color (PARRYWARE / equivalent).

Provision in plumbing for connecting one geyser in each toilet.

Hot and cold mixers for shower and tap in each toilet.

Bathroom CP fitting (PARRYWARE / equivalent) will be provided.

Health faucet will be provided in all toilets.

Water Supply

One common bore well and metro water sump will be provided.

Two pumps one for bore and one for sump will be provided.

One separate pump & separate overhead tank (may be separate portion of common overhead tank) with separate water lines shall be provided.

Electrical

Concealed copper wiring with FRLS Quality and Modular switches.

Separate meter for lighting in common areas, the lift and pumps.

Three phase power supply will be provided for each flat.

15 AMP power plug sockets will be provided for water heater in the toilet, for air conditioners in the bedrooms, two in the kitchen and one in the service balcony for washing machine.

In all the flats 5 AMP sockets will be provided in the kitchen, one for aqua guard, one for mixer machine and one for exhaust fan.

Two 5 AMP plug sockets will be provided in each room except that in the living room in addition a multiple socket with 3 outlets will be provided for connection to TV, Stereo and VCR.

One calling bell point will be provided.

Loft & Cupboard

One common name board and letter boxes for each flat built to design will be provided at the entrance to the building.

Concealed PVC pipes for TV and telephone will be provided in the living room and bedrooms.

The common area outside the building shall be paved and suitable landscaped.

Rain water harvesting will be carried out in the proposed building.

The flat is to be constructed to this specification subject to minor changes in dimension, locations found desirable or necessary to ensure sound engineering practice at the sole discretion of the Builder.
