Praveen Park in Perungalathur

STRUCTURE

RCC frame structure in 1:2:4 concrete

Reinforcement as per design

Height of floor level 4'0" above road formation level

Floor ceiling height shall be 10"

Roof slab shall be 5" thick

BASEMENT

9" thick brick work in CM 1:6 above plinth beam

6" thick PCC 1:4:8 above earth filling

WALL

9" thick brick outer walls in CM 1:6 and 4 1/2" thick partition walls in CM 1:5 Plastering with CM 1:4

CARPENTRY

Main door of teak plain design with all brass fitting and godrej cylindrical lock

Other door frames and of country wood and windows UPVC

Bedroom doors of quality flush doors painted

Bathroom door panels will be of Sintex PVC

LOFT/SHELVES

One loft in the shortest span in the bedrooms and kitchen

One open wardrobe with two cuddappah slabs without shutters of 4' length and 1'6" depth in bedrooms

One cub - board with four cuddapah slabs without shutters of 4' length and 1'0"depth in kitchen

SANITARY WARE AND PLUMBING

Standard EWC white with flush tank in attached toilet

Standard parryware IWC white in the other toilet

Standard washbasin (white) in dinning

Standard chrome platted taps (watermen or equivalent)

Washing machine provision

Vitrified flooring 2' x 2'

Black granite counter top and S.S. sink in kitchen

Plain ceramic wall cladding 2'0" in kitchen and 7'0" in bathrooms

Inter locking paver tiles

PAINTING

Emulsion painting above one coat of primer, two coats of wall patty in the inner walls and interior portion in the outer walls

French polish for main door

Synthetic enamel paint for wooden surfaces and grills
