Nahar Vibha in Thiruvanmiyur

TYPE OF CONSTRUCTION

Framed structure with R.C.C. columns & beams (as per soil report) over masonry walls of 9 inches and 4.5 inches walls plastered and paint finished.

Ceiling height will be 9'-6" feet approximately except in the toilet where it will be 8'-6".

Stilt Car Parking with three Floors with car parking for each flat.

FLOORING

Living, dining and bedroom area will be finished with good quality 2' * 2' vitrified tiles with 4” matching skirting tiles as per design & builder's choice.

Toilets will be finished with good quality antiskid ceramic flooring and glazed wall tiles up to 7 feet height as per builder's choice.

Balconies will be finished with good quality matt finished 1' * 1' antiskid tiles as per builder's choice.

PLUMBING & SANITARY

Concealed / open CPVC plumbing lines from the overhead tank will be provided.

All closets and washbasins (white colour) will be Parryware / equivalent fitting.

Hot and cold wall mixer will be provided for shower area.

All C.P. fittings will be Bath Sense/Johnson/Hindware or equivalent fitting.

DOORS

Living/Drawing, Dining, Rooms & Kitchen will be of 2 x 2 vitrified tiles

KITCHEN

Main doorframe will be of teak and door shutter will be of good quality imported skin, finished with lacquer varnish.

Other doors will be with good quality wood frames and flush doors laminated on both sides.

All door fittings will be of aluminium except the front main door, which will have brass fittings.>/p>

Main door will be provided with Godrej lock, door eye, tower bolt & door stopper.

Doors to the bedrooms will be provided with Godrej cylindrical locks.

Door and frame will not be provided for kitchen.

LOFTS

One in the kitchen and one in each bedroom will be provided.

PAINTING

Acrylic putti will be applied on the ceiling and the walls of flats to have smooth surface and finally finished with one coat of acrylic primer.

All wooden frames, shutters and M.S. Grill will be finished with enamel paint.

The building exterior, including balconies, will be finished with cement plaster & waterproof paint as per builder's choice.

The staircase area will be finished with cement plaster & acrylic emulsion as per builder's choice.

ELECTRICAL

Concealed copper wiring suitable for three-phase supply, will be of ISI quality from Anchor.

Switches & sockets with adequate points for light, fan and power supply will be provided of Anchor Roma Brand.

Separate meter for lighting in common areas and the pumps.

Three phase electric supply connection will be provided for each flat.

One calling bell point will be provided.

Provision for UPS wiring will be provided.

Provision for Split Air Conditioner in all bedrooms.

WATER SUPPLY

One common bore well and one sump will be provided.

One submersible pump for bore well and one pump for sump with water level indicators will be provided.

GENERAL

Anti-termite treatment

Aqua guard point in kitchen.

An automatic water level controller for pumps will be provided.

One individual letterbox will be provided at the entrance to the building.

Concealed PVC pipes for TV antenna will be provided in the living room and bedrooms.

A common board will be provided near the entrance to the building for incoming telephone lines, with provision for concealed wiring from this board to points in each flat in the living room and the bedrooms.

Rain water harvesting
