Nahar Jasoda

STRUCTURE

R.C.C. framed structure with R.C.C. Columns, beams and slabs - Based on Soil Testing Report.

Height of the roof will be maintained at 10'0” and the top floor roof will be at 10'6” (Roof top to Roof top measurement)

Brick Masonry walls, External - 9” & Internal - 4.5”

Stilt cum Ground Floor Car Parking with Five Floors with car parking for each flat.

JOINERY

Frame — I Class Teak wood. Frame thickness is 5” X 3” with bottom.

Shutters will be of imported teak finish skin flush door finished with melamine polish

Frames - II Class Teak wood.

Shutters will be of solid core flush door finished with laminates on both sides.

WINDOWS

UV. resistant poly vinyl windows with grills - FENESTA or equivalent.

FLOORING

Living/Drawing, Dining & Rooms will be of 4x2 GVT Flooring - KAJARIA or equivalent.

KITCHEN

BLACK GRANITE slab over cooking platform on the eastern side.

Stainless Steel kitchen sink with drain board - FRANKE $S304 GRADE

Ceramic tile dado about 2'-0” height above platform

SANITARYWARE

JAQUAR, KOHLER, ROCA or equivalent make wall hung coupled closet with hush seat cover & Wash Basins.

C.P. fittings will be JAQUAR make Florentine series, KOHLER, ROCA or equivalent.

VENTILATOR

Aluminium louver with Glaze Finishing & M.S. Grill with two coats of enamel paint.

WATER SUPPLY

One Sump

Overhead tank

Supply in the kitchen for Corporation Water

Ground Water to Bath, Toilet and Kitchen through Overhead Tank

LOFTS

One in kitchen and in all bedrooms will be provided

ELECTRICAL

Three phase electric supply connection

Concealed copper wiring & points for Fan, Light, Telephone, T.V., Fridge, Geyser, AC, Washing Machine and Grinder will be provided.

MCB (Miniature Circuit Breakers) & RCCB (Residual Current Circuit Breaker) will be provided.

Wiring will be of Anchor. Modular Switches of Anchor Roma or equivalent.

STAIR CASE

Granite with S.S. Railing

ADDITIONAL

Name Plates

Video Intercom and CCTV Camera of Eurovigil by TATA or equivalent.

Back-up Generator for common area lights, motors, lift & for all fans, lights and 5 Amps Plug Point in the apartment.

Rain water harvesting
