JVP Pride

Civil Works:

R.C.C. Framed structure using columns and beams as per as the Structural design.

Excavation: Column foundation with 5'0" depth Basement raised level will be raised up to 2'0" from the existing road level.

All external walls with 6" thick Solid block and internal 4" thick Solid block.

R.C.C. work of M-20 Grade (with a roof height of 10'0")

One Loft will be provided on the shorter side of all bedrooms and in kitchen.

Parapet wall consist of 4" Solid Block up to the height of 2'0".

External Plastering in C:M 1:5 with sponge finished surface.

Internal Plastering in C:M 1:5 with smooth finished surface

Tiles Work:

Flooring -Vitrified double charge 2'x2" flooring @ Cost of Rs.40 rs/sq ft for all Bedrooms, Hall, Kitchen and Dining.

Toilets wall tile will be done up to 7'0" height (Rs.30/-) of approved color and Anti-skid tiles for flooring.

Kitchen counter slab will be provided with Granite of rate 100 rs/sq ft and stainless steel sink of rate 2000 Rs will be provided with 2'0" height wall tiles of range 30 rs/sq ft above the counter.

Staircase area - Tile flooring 1"x 1" with MS Hand Railing.

Electrical Works:

Internal Concealed electrical conduits with metal boxes.

All Electrical cables will be of Orbit Brand.

Necessary MCB's with Isolator will be provided.

Switches - Local Switches

All wiring will be concealed and Designed for 3 phase power supply.

Carpentary Works Main Door:

Flush Door with Veneer, Sal wood frame of size 5"x 3", worth Rs 15000 including Fittings.

Internal Doors-Enamel Painted Skin Panel Door and Frame of size 4"x3" worth Rs 9000 including Fittings.

First Quality PVC doors for Tollets-Basic cost 2500 Rs.

All windows will be of sliding white powder coated Aluminiumwith 5mm thick plain glass and fixed grill of 12mm square rod at a spacing of 5"x5" c/c.

Ventilators of Aluminium (Louver type) with necessary glass.

Plumbing Works:

Internal Plumbling line will be concealed with VCPVC pipes- Un Brand and PVC pipe with Un Brand.

SS finished CP fittings will be provided One White EWC/IWC of local brand white color will be provided in each toilet.

2 in 1 wall mixer & one shower point will be provided in each toilet.

One white wash basin 12"x 18" size will be provided in each toilet.

Necessary floor sump, man hole with cover will be provided for external sewage.

Paintings:

Internal Wall-2 Coat Putty, 1 Coat Primer with 2 Coats of Tractor Emulsion Paint.

Ceiling-1 Coat white Cement and 2 Coat Tractor Emulsion Paint.

Exterior Wall-1 Coat of Dr Foxit Primer and 2 Coat Ace Emulsion Paint.

Main door-Fully teak wood varnish.

Other Doors and Grills - Enamel Pain.

TRANSPOTATION

Anakaputhur Bus Stand. _ 9 Mins

Kundrathur Bus Stand _ 15. Mins

400 Out Ring Road. -- 15 Mins

Porur Bus Stand. _ 18 Mins

Porur Metro Station. -- 15 mins

SCHOOL &. COLLEGES

Madha Medical College. -- 5 Mins

Madha Arts and Science College. -- 10. Mins

St. Joseph 's Arts and Science College. -- 5 Mins

Kidzee pre School. -- 10 Mins

The PSBB Millennium School. --- 10 Mins

Lalaji. Memorial Omega International. School. -- 15 Mins

Sri Ramachandra Medical College &. Hospital. --- 25 Mins

HOSPITAL

Madha super speciality hospital -- 4mins

Annai. Grace Hospital. -- 15 Mins

BP Jain. Hospital. --- 16. Mins

Rela Hospital. --- 30 Mins

Miot Hospital. --- 25 Mins

IT. PARKS

Upcoming prestige IT Park 18mins

RMZ Software park --20 Mins

DLF IT Park / L& T IT Park. -- 22 Mins

Virtus. Hub. -- 26 mins

Olympia Technology Pvt Ltd -- 28 mins

LOCATION. HIGHLIGHTS

Connecting Tambaram By Pass. -- 7 mins

Kundrathur Murugan Temple. --- 18 mins

Mangadu Temple -- 10 mins

Chennai International Airport -- 25 Mins
