Type of Construction
RCC Framed Structure
Walls
Walls will generally be plastered and painted (Asian Paints / Nerolac / Berger) inside and outside
In the toilets, wall will be covered with ceramic tiles up to 7 feet height
In the wash area, ceramic tiles will be provided upto the parapet wall height or will be in line with kitchen dado
Ceramic tiles will be plain soft color of builder’s Choice
Flooring
Flooring will be good quality 2 X 2 vertified tiles for entire flat except in 2 bed rooms (including on Master bedroom) toilet and wash area.
Toilet and wash area will be provided with 1 X 1 ceramic tiles.
Master Bed room and one more bedroom (of purchaser’s choice) will be provided with wooden flooring.
Doors
Main door frame will be of 1st Quality teak wood doors finished with varnish with Brass fitting.
Other doors will be good quality wood frames flush doors or equivalent painted on both sides.
Windows and Ventilators
Pre-fabricated UPVC Bay windows for Master bedroom & others standard size windows will be provided
Freanch sliding windows for Hall Sit-out
2x2 size Ventilators with glass louvers& Fan exhaust ventilationfor toilets
Kitchen
G 20 Black Granite slab will be provided for the kitchen cooking platform
A Single bowl stainless steel sink with drain board will be provided
Plumbing and Sanitary Fittings
Concealed plumbing lines from the overhead tank for each floor
All closets and wash basins will be in white color (PARRYWARE / equivalent)
Provision in plumbing for connecting one geyser in each toilet
Hot and cold mixers for shower and tap in each toilet
Bathroom CP fitting (PARRYWARE / equivalent) will be provided
Health faucet will be provided in all toilets.
Water Supply
One common bore well and metro water sump will be provided
Two pumps one for bore and one for sump will be provided
One separate pump & separate overhead tank (may be separate portion of common overhead tank) with separate water lines shall be provided
Electrical
Concealed copper wiring with FRLS Quality and Modular switches
Separate meter for lighting in common areas, the lift and pumps
Three phase power supply will be provided for each flat
15 AMP power plug sockets will be provided for water heater in the toilet, for air conditioners in the bed rooms, two in the kitchen and on in the service balcony for washing machine
In all the flats 5 AMP sockets will be provided in the kitchen, one for aqua guard, one for mixer machine and one for exhaust fan
Two 5 AMP plug sockets will be provided in each room except that in the living room in addition a multiple socket with 3 outlets will be provided for connection to TV Stereo and VCR
One calling bel point will be provided
Loft & Cupboard
One common name board and letter boxes for each flat built to design will be provided at the entrance to the building
Concealed PVC pipes for TV and telephone will be provided in the living room and bed rooms
The common area outside the building shall be paved and suitable landscaped
The flat is to be constructed to this specification subject to minor changes in dimension, locations found desirable or necessary to ensure sound engineering practice at the sole discretion of the Builder
