Aswin Gopi Nivas

Structure

R.C.C. framed structure and brick walls with Cement mortar.

Foundation

Column Footing. (Footing based on Soil Test Report)

Roof

Reinforced cement concrete roof. (Based on Structural Engineer Report)

Flooring

Vitrified Flooring tiles (2’.0” x 2’.0”) Size of Johnson Tiles or Imported Tiles

Walls

Clay Red Brick or AAC BrickWalls with 9 inches wall CM 1:6 and 4 ½ inches wall CM 1:5.

Wall plastering 1:3 in 12mm thickness.

Doors

Main Door Teak wood, other doors frame Teak wood and moldableshutters Flush door.

Cement

Birla or Deccan

Bricks

AAC Bricks or Clay Bricks

Steel

ARS Steel 500

Windows and Door frames

UPVC Windows with M S Grill

Ventilators

Glazed Sand louvers with security bars.

Kitchen

Semi Modular Kitchen – to each JV Owner – Only for any 1 (One) Flat

Kitchen top Granite stone G20 black color – 2 ft. height wall Tiles with stainless steel sink covered.

Toilet

Two Western Hindware Closet wall mounted (White colour) Jaguar fittings, bath room tiles Size 10’*15’ with Johnson Tiles.

Wall Painting

The internal wall painted with emulsion roller Finish and external walls shall be painted with cement paint one coat ACE paint, ceiling

Emulsion two coats of Half white colour.

Two coat wall putty will be done in walls and celing.

Wood Painting

The Doors and window grill shall be painted with paint two coats

Synthetic enamel over a cost of premier. Brand: Asian Paints

Electrical wirings

Concealed PVC wiring with ISI standardBrand: Orbit or Finolex

Switches (MK) Switches

Electrical points

Hall 4 light points and 2 fan points, 1plug point, 1 TV point, 1 Telephone point,

Dining 1 fan point, 1 light point, 1 plug point,1 Fridge Point

Bedroom 1 2 light points, 1 Fan point,1 plug point,1A/c point.

Bedroom 2 2 light points, 1 Fan point, 1 plug point,1A/c point

Bedroom 3 2 light points, 1 Fan point, 1 plug point,1A/c point

Pooja 1 Light Point and 1 plug Point

Kitchen 2 light points, 2 plug point of 15Ams and 3 plug point of 5Ams

Varandah 1 light point, 1 washing machine points

Plumbing

Plumbing with PVC or UPVC pipes, 3 wash basin of Hindware Brand white colour One in Dining Area,One in Master Bedroom and One in attached Bedroom.

Common Area

Corridor Marble, Granite for Steps. Granite Cladding for Lift Walls. S.S Railing for Staircase.

Weathering Course

Cooling Tiles.

Generator Backup

Kirloskar Brand.Will be connected in common light points, lift, Motor, Minimum points will be connected for all the flats.

Lift

Johnson Lift

Borewell

2 Bore wells,1 motor model depends on depth.

RCC Sump

12,800 Litre, 1 sump motor- Monoblock model.

Tank Capacity

2 No.s of water Tank will be provided in the Terrace.

Each with 3500-4000 litre Capacity.
